Name: SS 304 Stainless Steel Coil Sheet ASTM AISI Standard
Brand: jinshunlai
SKU: 0.1mm-900mm
Rating: 4.8 (140 reviews)

Home > products > Stainless Steel Coil Sheet >

SS 304 Stainless Steel Coil Sheet ASTM AISI Standard

ASTM Stainless Steel Coil Sheet

AISI Stainless Steel Coil Sheet

ASTM ss 304 coil

Place of Origin:

china

Brand Name:

jinshunlai

Certification:

ISO, AISI, ASTM, GB, EN, DIN

Model Number:

0.1mm-900mm

Document:

Product Brochure PDF

Request A Quote

SS 304 Stainless Steel Coil Sheet ASTM AISI Standard

Product Details

Certificate:

ISO, SGS, BV, Etc

Edge:

Slit Edge/Mill Edge

Length:

1000-6000mm

MOQ:

1 Ton

Material:

Stainless Steel

Package:

Standard Export Seaworthy Package

Payment:

T/T, L/C, Western Union, Etc

Price Term:

FOB, CFR, CIF, EXW, Etc

Standard:

ASTM, AISI, GB, JIS, DIN, EN

Surface:

2B, BA, HL, 8K, No.4, Etc

Surface Treatment:

Coil Sheet

Thickness:

0.1-3mm

Width:

1000-2000mm

Payment & Shipping Terms

Minimum Order Quantity

1kg

Price

Packaging Details

Waterproof Paper, Steel Strip Packed and other Standard Export Seaworthy Package, or customized package

Delivery Time

5day

Payment Terms

L/C, T/T , Western Union

Supply Ability

90000ton

RELATED PRODUCTS

+86-17763564398

sales01@shuangheyisteel.com

Contact Now

Product Description

PRODUCT DESCRIPTION

Beryllium Copper CuBe2 in Wire Form Used in The Electrical Indsutry

Product Description:

Name: Beryllium copper wire

Grade: CuBe2

Specification: Diameter 1.4mm

Surface: Bright

State: A(TB00), 1/4H(TD01), 1/2H(TD02), 3/4H(TD03, H(TD04)

Features: High strength and elestivity

Application: For electrical industry

Typical Physical Properties of Beryllium Copper CuBe2 Alloy:

Density (g/cm3):	8.36
Density before age hardening (g/cm3):	8.25
Elastic Modulus (kg/mm2 (103)):	13.4
Thermal Expansion Coefficient (20 °C to 200 °C m/m/°C):	17 x 10-6
Thermal Conductivity (cal/(cm-s-°C)):	0.25
Melting Range (°C):	870-980

Mechanical and Electrical Properties of Beryllium Copper CuBe2 Wires:

Alloy	Temper (*)	Heat Treatment	Tensile Strength Mpa	Elongation percent	Electrical Conductivity percent IACS
CUBERYLLIUM 172	A	/	400～580	30-60	15-19
	(TB00)
	1/4 H	/	570～795	3~25	15-19
	(TD01)
	1/2 H	/	710～930	2~15	15-19
	(TD02)
	3/4 H	/	840～1070	2~8	15-19
	(TD03)
	H	/	915～1140	1~6	15-19
	(TD04)
CUBERYLLIUM 172	AT	3 hr 315℃	1050~1380	3 min	22-28
	(TF00)
	1/4 HT	2 hr 315℃	1150~1450	2 min	22-28
	(TH01)
	1/2 HT	1.5hr 315℃	1200~1480	2 min	22-28
	(TH02)
	3/4 HT	1.0 hr 315℃	1250~1585	2 min	22-28
	(TH03)
	HT	1.0hr 315℃	1300~1585	1 min	22-28
	(TH04)

International Specification of Beryllium Copper CuBe2 Alloy:

Product Type	Temper Type
Bar	ASTM B196
Bar	Military Mil-C-21657
Rod	ASTM B196
Rod	Military Mil-C-21657
Wire	ASTM B197, AMS4725, SAE J461,463, RWMA Class 4
European Standards	CuBe2, Alloy 25, BrB2, DIN.2.1247, CW101C to EN

Note:

ASTM: American Society for Testing and Materials

SAE: Society of Automotive Engineers

AMS: Aerospace Materials Specification(Published by SEA)

RWMA: Resistance Welder Manufacturers' Association

Note: Unless otherwise specified, material will be produced by ASTM.
