Name: Electrical Conductive Copper Foil Shielding Tape 50mm Width
Brand: Jinshunlai
SKU: 0.1mm-900mm
Price: 5000 USD
Availability: InStock
Rating: 4.8 (194 reviews)

Home > products > Copper Foil Tape >

Electrical Conductive Copper Foil Shielding Tape 50mm Width

Electrical conductive copper foil

conductive copper foil Tape

50mm conductive copper shielding tape

Place of Origin:

china

Brand Name:

Jinshunlai

Certification:

IOS

Model Number:

0.1mm-900mm

Document:

Product Brochure PDF

Request A Quote

Electrical Conductive Copper Foil Shielding Tape 50mm Width

Product Details

Adhesive:

Acrylic

Adhesive Strength:

High

Application:

Electrical, Insulation, Shielding

Color:

Copper

Temperature Resistance:

Up To 80°C

Thickness:

0.06mm

Width:

50mm

Color:

Red Yellow

Payment & Shipping Terms

Minimum Order Quantity

1kg

Price

5000usd

Delivery Time

5day

Payment Terms

L/C, T/T , Western Union,D/P

Supply Ability

90000ton

Key attributes

Industry-specific attributes

Adhesive

Acrylic

Adhesive Side

Double Sided

Adhesive Type

Pressure Sensitive

Design Printing

No printing

Material

copper foil

Feature

ANTISTATIC

Use

Warning

Other attributes

Place of Origin

China

Brand Name

jinshunlai

Model Number

key word

high temperature resistance tape

Packaging & delivery

Selling Units:

Single item Electrical Conductive Copper Foil Shielding Tape 50mm Width 0

Single package size:

12X12X5 cm

Single gross weight:

0.200 kg

Package Type:

carton

Product Description

Conductive copper foil tape has low surface oxygen properties and can be attached to a variety of different substrates, such as metals, insulating materials, etc., with a wide temperature range.

It has strong bonding force, good electrical conductivity, eliminates electromagnetic interference (EMI) and isolates electromagnetic waves from harming the human body, avoiding the influence of unwanted voltage and current on function. In addition, it has a good effect on the static battery after grounding.

Mainly used in electromagnetic shielding and anti-static, the conductive copper foil is placed on the substrate surface, combined with the metal substrate, has excellent conductivity, and provides electromagnetic shielding effect.

Can be divided into: self-adhesive copper foil, double-lead copper foil tape, single-sided conductive copper foil / double-sided double-lead copper foil.

Detailed Images

parameter	single face with glue					double sided adhesive
copper foil thickness (mm)	9U±1	18U±2	25U±3	50U±3	100U±2	25U±1	50U±2
total thickness (mm)	20U±5	50U±2	60U±5	85U±5	150U±5	65U±5	120U±5
resistance (Ω)	≤0.05	≤0.05	≤0.05	≤0.05	≤0.05	≤0.05	≤0.05
180℃ stripping force KG/25mm	≥0.8	≥0.8	≥1.2	≥1.2	≥1.5	≥1.2	≥1.2
maintain force 1KG/25mm2 hours	≥48	≥48	≥48	≥48	≥48	≥48	≥48
long term temperature tolerance	80	80	80	80	80	80	80
short term temperature tolerance	120	120	120	120	120	120	120
